This large format, slimline wood burning and multi-fuel stove is perfect for settings where a shallower depth is required, without sacrificing flame visuals. Broader and taller than the Chesterfield 5, the Chesterfield 5 provides a 5kW heat output and can be selected in wood burning or multi-fuel models.
The Chesterfield family features our Convector Heat Flow system, which channels warm air between the firebox and the outer walls of the stove back into the room for enhanced heating performance. This innovative design feature also removes heat from the rear of the appliance, reducing the stove’s distance to combustibles for more installation possibilities. |
| Body material | Steel body - cast iron door |
| Rated output | 5kw |
| SIA Ecodesign |
Yes - more information |
| Smoke control area approved | Yes |
| Cleanburn / Airwash |
Yes |
| Efficiency | 80% |
| Room vent required |
No - *unless the house was built after 2008- See Doc J page 17 |
| External air supply option |
Yes |
| Flue connection | 125mm - top or rear interchangable |
| Maximum log length | 500mm |
| Fuel type |
Wood / Multifuel |
| Grate / Ashpan |
Multifuel version only |
| Suitable for 12mm Hearth | Yes |
| Weight | 102kg |
Wood version
Multifuel version
