 Arc 7 on log store  Arc on store stand  Charnwood Arc on low stand  Quatraflow system The Quattroflow Air Management System is a revolutionary air management system patented by Charnwood and used on the Aire, Skye, Arc, Cove, Island, Bay, Bembridge and C-Series models.  External air supply The external air kits are a range of devices that enable an outside air supply to be channeled directly into your Charnwood stove.
As well as providing further comfort and operational efficiency for your stove our air kits help overcome issues where the room requires an additional air supply. They are available for all Aire, Skye, Arc, Bay, Cove, Island, C-Series and Bembridge dry models.  Converting grate The very best grate system on the market, our converting grate optimises efficiency and burning conditions.  click the images to enlarge |
The Charnwood Arc 7 delivers an output of 7kW and is particularly suited to larger rooms or open plan areas. It is a true multi-fuel stove with exceptional clean burn technology. The Arc 7’s contemporary design features an inverted flue collar for a seamless flue connection.
|
| Body material | Steel body - cast iron door |
| Rated output | 7kw |
| SIA Ecodesign |
Yes - more information |
| Smoke control area approved | Yes |
| Cleanburn / Airwash |
Yes |
| Efficiency | 84% |
| Room vent required |
Yes |
| External air supply option |
Yes |
| Flue connection | 150mm - top or rear interchangable |
| Maximum log length | 300mm |
| Fuel type |
Multifuel |
| Grate / Ashpan |
Grate & Ashpan - Converting grate |
| Suitable for 12mm Hearth | Yes |
| Weight | 140kg |
Low Stand
Store stand
Vertical rear flue adaptor
External Air Kit
